It has a 6 hole brake disc mount
+ ability to use a second disc after using a screw-on adapter ( not included - ask if You need this part)*
Mounting width OLD: 135 mm ( FATBIKE system - unusual for regular bikes )
Rigid axle 190 mm long / 10 mm diameter
Number of holes for spokes: 144
Spoke hole 14G = 2 mm
Spoke hole spacing internal ~ 68 mm / external ~ 75 mm
Flange distance ~ 83 mm.
Weight ~ 770 gr
* second disc adapter is not included with the hub, ask for availability before ordering if you plan to use it.
Perfect for custom designs, for 80 / 100 mm rim width
or FatBike forks
The hub does not fit classic OLD 100 mm forks
Sample picture using with 2 discs:
