Axle 13/32 - length 183 mm
*OLD - mounting width in fork 135 mm
ATTENTION ! the Over Locknut Dimension / width of the mounts / dropouts in the rear fork - OLD 135 mm - is unusual for this type of hubs - fits MTB bikes with cassette and derailleur
Gear Ratio
• Overall Range - 243%
• Gear 1 - 64% (Gear 2 - 25%)
• Gear 2 - 80% (Gear 3 - 25%)
• Gear 3 - 100% (Direct Drive)
• Gear 4 - 125% (Gear 3 + 25%)
• Gear 5 - 156% (Gear 4 + 25%)
• 6061 Aluminum hub shell
• 36 spoke holes
• INCLUDES 18 T SPROCKET
for 1/2"-1/8" chain
• Weight - 2014g
