• material of frame and fork: steel
• bottom bracket FAT-BSA 100 mm wide
• seatpost 27,2 mm
• seat-clamp integrated with the frame
• frame width between chain stays O.L.D. 170 mm - ø 10 mm axle
• front fork O.L.D. 135 mm - ø 10 mm axle
• disc brake mount (IS)
• width of the front and rear fork at the tire run area 12 cm
Seattube to Headtube 55,5 cm
Seattube-top-end to Bottom Bracket axis 45,5m
rear fork - hub axis to BB axis 47 cm
max. wheel radius with tire 38 cm
Head Tube 1 1/8" Length 12,5 cm
We recommend to use outside 1-1/8" AHEAD headset - for example Neco H865
